Galeco HIDDEN GUTTER system

Gutter
system

Galeco HIDDEN
GUTTER

Perfectly
integrated

Gutter
system

HIDDEN GUTTER

Galeco HIDDEN GUTTER

Inspiration for designers

The Galeco HIDDEN GUTTER system was created to support architects and designers working on unconventional architectural forms.

This innovative Galeco solution allows the gutters to be integrated discreetly into the facade.

Quick assembly and disassembly of the duct cover

The system enables easy attachment of the cover, which hides the gutters and creates a smooth eaves finish.

Rectangular gutter and pipe profile

The rectangular gutter and downpipe profile, combined with the cover, helps achieve a modern building form.

10-year warranty

The warranty covers resistance to perforation corrosion, mechanical durability and system tightness.

CAD/BIM support for architects

Specially prepared CAD/BIM drawings help architects and designers include the system in their projects.

Increased system tightness

A properly installed HIDDEN GUTTER system is completely safe, meaning the risk of leakage is eliminated.

Heating cable system

It prevents the accumulation of snow and ice, as well as the freezing of water in gutters and downpipes.

Galeco HIDDEN GUTTER System components

  1. Right endcap STEEL *
  2. Right endcap PVC *
  3. Metal support bracket for cover
  4. Dilatation connector
  5. Gutter
  6. Gutter strip with opening and gasket
  7. Outlet basket
  8. Outlet with socket and gasket
  9. Over-gutter strip
  10. Cover
  11. External connector to the cover
  12. Internal corner for cover
  13. Internal corner 90°, glued
  14. External corner 90°, glued
  15. External corner for cover
  16. Left endcap PVC *
  17. Left endcap STEEL *
  18. Left endcap for cover
  19. Right endcap for cover
  20. Socket with gasket
  21. Pipe
  22. Pipe bracket
  23. Double-thread pin with long sleeve
  24. Reducer 70 x 80 to 110
  25. Sewer pipe
  26. Sewer elbow 88°
  27. Drain box with extension, grate, separators and basket
  28. Elbow 67°
  29. Custom side elbow
  30. Offset pipe
  31. Custom side branch
  32. Flexible elbow with gasket 80 x 70 mm
  33. Heat-insulating housing of the downpipe

Optimal connection

Galeco HIDDEN GUTTER System was created as a combination of two materials.

STEEL – the highest-quality material. The steel core is galvanized and coated with a polymer layer, ensuring durability for years.

PVC-U – the most economical material in the Galeco offer, while ensuring high utility quality for many years.

See elements

Face bracket

The face bracket is made of uniform material without riveted components, which increases its stability. A single latch in the lower part reduces stress in the attached cover, and the additional bend on the nose makes installation on the gutter drip edge easier.

Learn more
Face bracket

Technical information

The Galeco HIDDEN GUTTER system is an innovative gutter system designed for installation in the insulation layer of buildings without traditional eaves.

The system consists of a steel rectangular gutter, 125 mm wide, and a PVC-U downpipe sized 70 x 80 mm.

Dilatation connector

Dilatation connector

The front connector is an innovative Galeco solution that enables tight connection of rectangular gutters. The gasket allows expansion between connected gutters while ensuring 100% system tightness.

Cross-section of the gutter and downpipe connection

Cross-section of the gutter and downpipe connection

Efficiency table

Gutter type / Downpipe size

Downpipe position125 / 70x80
90 m2
180 m2

Galeco HIDDEN GUTTER System was created as a combination of two materials

STEEL
The gutter and the cover are made of high-quality coated steel. A galvanized steel core with primer and organic coating ensures long-term durability.

PVC-U
PVC-U is used for downpipes installed in the facade and not exposed directly to weather conditions. It helps reduce the cost of the full gutter system while maintaining high utility quality.

Galeco HIDDEN GUTTER System was created as a combination of two materials
Information about sizes

Information about sizes

Galeco HIDDEN GUTTER System is available in one size: 125/70×80. It is used for guttering single-family houses, residential buildings and small industrial facilities, including roofs without eaves.

Thanks to the rectangular profile, the gutter is more efficient than competing round 125 mm gutters. The rectangular pipe is designed to hide the entire downpipe in the building insulation.

Gutter colour schemes

Gutter type / Downpipe size

Colour RAL125 / 70x80
Graphite RAL 7015
Black RAL 9005
Dark silver RAL 9007

Duct cover colour schemes

Colour RAL.
Graphite RAL 7015
Graphite MATTE RAL 7016
Black RAL 9005
Black MATTE RAL 9005
Dark silver RAL 9007
Special-purpose face bracket

Special-purpose face bracket

The specially designed face bracket has latches in its lower part, allowing the cover to be snapped into place. This component can be removed at any time to carry out gutter maintenance.

The cover, bracket and gutter are Galeco technical solutions legally protected by the Polish Patent Office.

System elements

Gutter 4 RM

Gutter 4 RM

PRODUCT CODE:
1041-125-_-RYN400
Gutter 3 RM

Gutter 3 RM

PRODUCT CODE:
1041-125-_-RYN300
Metal support bracket

Metal support bracket

PRODUCT CODE:
1041-125-_-HDM000
Dilatation connector

Dilatation connector

PRODUCT CODE:
1041-125-_-LAR000
Outlet 125/80×70 mm with socket with gasket

Outlet 125/80×70 mm with socket with gasket

PRODUCT CODE:
1061-125-_-OPK080
Internal corner 90°

Internal corner 90°

PRODUCT CODE:
1041-125-_-LWK090
External corner 90°

External corner 90°

PRODUCT CODE:
1041-125-_-LZK090
Flexible elbow with gasket 80×70 mm

Flexible elbow with gasket 80×70 mm

PRODUCT CODE:
1062-080-905S-KEL000
Elbow 67°

Elbow 67°

PRODUCT CODE:
1022-080-_-KOL067
Pipe 4 RM

Pipe 4 RM

PRODUCT CODE:
1022-080-_-RUR400
Custom side elbow

Custom side elbow

PRODUCT CODE:
1062-080-_-KOBXXX
Offset pipe 1-9 cm

Offset pipe 1-9 cm

PRODUCT CODE:
1062-080-_-KOS000
Custom side branch

Custom side branch

PRODUCT CODE:
1062-080-_-TRBXXX
Gutter strip 2 RM

Gutter strip 2 RM

PRODUCT CODE:
1061-125-_-PAS200
Left endcap

Left endcap

PRODUCT CODE:
1041-125-_-ZLS000
Right endcap

Right endcap

PRODUCT CODE:
1041-125-_-ZPS000
Heat-insulating housing of the downpipe 1.2 RM

Heat-insulating housing of the downpipe 1.2 RM

PRODUCT CODE:
1062-080-000X-RUT120
Socket with gasket and cyanoacrylate adhesive

Socket with gasket and cyanoacrylate adhesive

PRODUCT CODE:
1062-080-_-MUF000
Internal pipe bracket

Internal pipe bracket

PRODUCT CODE:
1022-080-_-OBS000
Reducer

Reducer

PRODUCT CODE:
1003-080-738S-RED110
Cover 2 RM

Cover 2 RM

PRODUCT CODE:
1061-000-_-DMS200
External corner for cover

External corner for cover

PRODUCT CODE:
1061-000-_-DNZ000
Internal corner for cover

Internal corner for cover

PRODUCT CODE:
1061-000-_-DNW000
Soffit cover endcap left

Soffit cover endcap left

PRODUCT CODE:
1061-000-_-DZL000
External connector to the cover

External connector to the cover

PRODUCT CODE:
1061-000-_-DLA000
Soffit cover endcap right

Soffit cover endcap right

PRODUCT CODE:
1061-000-_-DZP000
Elbow 88°

Elbow 88°

Outlet leaf guard

Outlet leaf guard

Drain box cover

Drain box cover

Drain box – set

Drain box – set
